- Aluminum Superlite Frame Gravity Casting Technology
- Efficient Comfort Geometry
- Bosch Drive Unit Performance Generation 3, 65Nm torque
- Bosch PowerTube 500 Battery
- Assist speeds up to 32 km/h
- Approx range 75km - 140km
- Shimano 1 x 9 Speed Drivetrain
- Tektro Hydraulic Disc Brakes
Accessories: | Kickstand: CUBEstand Cmpt / Easy Bell / ACID Semi-Integrated Carrier, ACID RILink Adapter Compatible |
---|---|
Battery: | Bosch PowerTube 500, Charger: Bosch 2A |
Brakes: | Tektro HD-M275 Disc brakes |
Chain: | KMC X9 |
Crankset: | ACID E-Crank, 40T, 175mm (EE: 170mm) |
Derailleur rear: | Shimano RD-M3100-SGS, 9-Speed |
Display: | Bosch Purion |
Fender: | ACID 65 BB-Mount |
Fork: | SR Suntour NVX30 Coil, 100mm |
Frame: | Aluminium Superlite, Gravity Casting Technology, Efficient Comfort Geometry, Tapered Headtube, Full Integrated Battery, Semi-Integrated Carrier |
Freewheel: | Shimano CS-HG201, 11-36T Cassette |
Grip: | Natural Fit Comfort |
Handlebar: | CUBE Comfort Trail Bar, 700mm |
Handlebar stem: | CUBE Performance Stem Pro, 31.8mm |
Headset: | M/Z: ACROS AZF-1039, 1 1/8" straight, Top Zero-Stack 1 1/8" (ZS 44mm), Bottom Zero-Stack 1 1/2" (ZS 56mm) // EE: ACROS AZX-1041, BlockLock 135°, 1 1/8" straight, Top Zero-Stack 1 1/8" (ZS 44mm), Bottom Zero-Stack 1 1/2" (ZS 56mm) |
Hubs: | FRONT: Shimano HB-TX505, QR, Centerlock / REAR: Shimano FH-TX505, QR, Centerlock |
Light(s): | FRONT: CUBE Shiny 50 Lux, 12V, DC / REAR: ACID Mudguard Rear Light PRO-E, 12V, DC |
Motor drive unit: | Bosch Drive Unit Performance Line Cruise 20pmh Gen3 US (2020) |
Pedals: | ACID PP Trekking |
Rim: | CUBE EX23, 36H, Disc, Tubeless Ready |
Saddle: | Natural Fit Sequence Comfort |
Season: | 2022 |
Seat clamp: | CUBE Varioclose, 34.9mm |
Seat post: | CUBE Performance Post, 30.9mm |
Tyre front: | Schwalbe Big Ben, Active, 55-622 |
Tyre rear: | Schwalbe Big Ben, Active, 55-622 |
Weight: | 25.1kg / Maximum bike and rider weight: 135kg / Maximum system weight (incl luggage): 140kg |
Wheel size: | 700c |
SIZE | Trapeze 46 cm / XS | Trapeze 50 cm / S | Trapeze 54 cm / M |
SEAT TUBE | 440 | 480 | 520 |
TOP TUBE HORIZONTAL | 584 | 595 | 606 |
SEAT TUBE ANGLE | 73 | 73 | 73 |
HEAD TUBE ANGLE | 69.5 | 69.5 | 69.5 |
CHAIN STAYS | 488 | 488 | 488 |
HEAD TUBE | 105 | 115 | 135 |
WHEELSBASE | 1139.9 | 1151.5 | 1163.6 |
BB-HEIGHT TO HUB | 67.5 | 67.5 | 67.5 |
STANDOVER HEIGHT | 796.4 | 770.1 | 780.3 |
REACH | 392.6 | 400.6 | 406.6 |
STACK | 626.5 | 636.2 | 654.6 |
STEM LENGTH | 75 | 75 | 90 |
ANGLE STEM | 17 | 17 | 17 |
HANDLEBAR WIDTH | 700 | 700 | 700 |
LENGTH SEAT POST | 350 | 350 | 350 |
DIAMETER SEATPOST | 30.9 | 30.9 | 30.9 |
CRANK LENGTH | 175 | 175 | 175 |
DIAMETER TIRE MAXIMUM | 755 | 755 | 755 |
WIDTH TIRE MAXIMUM | 60 | 60 | 60 |
