Features
Marin Alpine Trail C2 Enduro Bike Black/Silver
5% Best Price Guarantee
If you find a cheaper price, we will beat it by 5%*
- Applies to any cheaper price found in New Zealand.
- When the competitor's final price inclusive of any taxes and delivery fees.
- Excludes Garmin products, other exclusions apply.
Perfect Ride Guarantee
If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »
Free Bike Build
We'll build your bike for free when you click and collect at any 99 Bikes store.
First Free Tune-up
Every bike come with a complimentary free tune-up and safety check. Learn more »
- Unidirectional Carbon Fiber Front Triangle, Series 4 Alloy Rear End
- Fox 38 Performance Elite, 160mm Travel
- Fox Float DPX2, Performance, EVOL Air Spring Shock
- Shimano SLX 1 x 12-Speed Drivetrain
- Shimano SLX, 4-Piston Hydraulic Disc Brakes
- Maxxis Assegai 29 x 2.5”, MAXX TERRA, EXO+, Tubeless Ready
| Bottom bracket: | MEGAEVO BB, 73mm BSA Threaded |
|---|---|
| Brakes: | Shimano SLX Hydraulic Disc, I-Spec EV, 4-Piston |
| Chain: | KMC X-12 Silver and Black |
| Crankset: | FSA Gradient, Modular 1x, |
| Derailleur rear: | Shimano XT 12-Speed, SGS |
| Fork: | Fox 38 Performance Elite, 160mm Travel, 29" , 110x15mm Boost Kabolt Thru-Axle, 44mm Offset, Integrated Fox Fender |
| Frame: | All New Unidirectional Carbon Fiber Front Triangle, Series 4 Alloy Rear End, 29 Wheels, 150mm Travel MultiTrac Suspension Platform, Internal Dropper Post and Rear Derailleur Routing, Chainstay Mounted Post Mount Disc Brake, 148x12mm Boost Thru-Axle, 73mm |
| Freewheel: | Shimano SLX M7100 Cassette, 12-Speed, 10-51T |
| Handlebar: | Deity Ridgeline, Stealth Finish, 35mm Clamp, 800mm Width |
| Handlebar stem: | Deity Copperhead, 35mm |
| Headset: | FSA No 57, Sealed Cartridge Bearings, 1 1/8" x 1 1/2 |
| Hubs: | FRONT: Shimano HF-MT410B, 110x15mm, Centerlock / REAR: Shimano HB-MT510B, 148x12mm, Centerlock, Microspline Freehub Body |
| Rim: | Marin, Double Wall Alloy, 29mm Inner, Welded Joint, Disc Specific, 32H, Tubeless Compatible |
| Rotor front: | 203mm Rotor |
| Rotor rear: | 180mm Rotor |
| Saddle: | Marin Trail Speed Concept Pro |
| Season: | 2022 |
| Seat post: | X-Fusion Manic, Size S 125mm Travel, 30.9mm |
| Spokes: | 14g Black Stainless Steel |
| Tyre front: | Maxxis Assegai 29x2.5, MAXX TERRA, EXO+, Tubeless Compatible |
| Tyre rear: | Maxxis Assegai 29x2.5, MAXX GRIP, DoubleDown, Tubeless Compatible |
| Weight: | 16kg |
| Wheel size: | 29" |
| S / 15.5" | M/ 16" | L / 16.5" | XL / 17" | |
|---|---|---|---|---|
| Stack | 619 | 628 | 632 | 643 |
| Reach | 430 | 455 | 480 | 515 |
| Headtube Angle | 63.5° | 63.5° | 63.5° | 63.5° |
| Headtube Length | 100 | 110 | 115 | 130 |
| Seattube Angle | 78° | 78° | 78° | 78° |
| Seattube Length | 390 | 400 | 425 | 430 |
| Toptube Effective | 561.7 | 589 | 615 | 652 |
| BB Height | 342 | 342 | 342 | 342 |
| BB Drop | 35 | 35 | 35 | 35 |
| Chainstay | 430 | 430 | 430 | 430 |
| Wheelbase | 1199 | 1229 | 1256 | 1297 |
| Standover Height | 690 | 694 | 695 | 698 |
| Fork Offset | 44 | 44 | 44 | 44 |
| Seatpost Diameter | 30.9 | 30.9 | 30.9 | 30.9 |
| Handlebar Width | 780 | 780 | 780 | 780 |
| Stem Length | 50 | 50 | 50 | 50 |
| Crank Length | 170 | 170 | 170 | 170 |
All lengths in millimeters
Marin Alpine Trail Bike Sizing Chart
Marin Bikes are Made For Fun. Since the first mountain bikes bearing the Marin name debuted in 1986, the brand has been dedicated to enriching the lives of riders by making fun, high caliber bicycles, which provide years of riding enjoyment. They operate their business based on hard work, fueled by passion, and fulfilled by the satisfaction of bringing the joy of cycling to riders across the world.
