- Premium Swiss engineered BMC Carbon Frame and Fork
- Endurance Tuned Compliance Concept (TCC)
- D-Shaped Carbon seatpost, integrated seat clamp
- Shimano Ultegra Di2 2 x 12-speed groupset
- Shimano Ultegra hydraulic disc brakes
- CRD-321 tubeless ready carbon wheelset
- Vittoria Rubino 28mm tyres, clearance up to 33mm
Brakes: | SHIMANO Ultegra - RT-MT800 |
---|---|
Chain: | SHIMANO Ultegra 12spd |
Crankset: | SHIMANO Ultegra 12spd 50-34T |
Derailleur rear: | SHIMANO Ultegra Di2 12spd |
Fork: | Roadmachine Premium Carbon with Tuned Compliance Concept Endurance, Internal Cable Routing, Flat Mount Disc, 12x100mm Thru-Axle |
Frame: | Roadmachine Premium Carbon with Tuned Compliance Concept Endurance, Internal Cable Routing, PF86 Bottom Bracket, Flat Mount Disc, 12x142mm Thru-Axle |
Freewheel: | SHIMANO Ultegra 12spd 11-34T |
Handlebar: | BMC RAB 02 - Ergo Top Shape - Compact Bend |
Handlebar stem: | BMC ICS1 |
Hubs: | CRD-321 |
Rim: | CRD-321 Carbon - Tubeless Ready - 35mm |
Rotor front: | 160mm |
Rotor rear: | 140mm |
Saddle: | Fizik Taiga |
Season: | 2023 |
Seat post: | Roadmachine Premium Carbon D-Shaped Seatpost, 15mm Offset |
Tyre front: | VITTORIA RUBINO - 700c x 28mm |
Tyre rear: | VITTORIA RUBINO - 700c x 28mm |
Weight: | Weight Limit: 110kg |
Wheel size: | 700c |
Size | 47 | 51 | 54 | 56 | 58 | 61 |
---|---|---|---|---|---|---|
Rider Height CM | <166 | 166-174 | 172-180 | 178-186 | 184-192 | >190 |
Stack MM | 516 | 541 | 562 | 586 | 610 | 644 |
Reach MM | 374 | 382 | 386 | 390 | 394 | 398 |
Seat Tube MM | 420 | 457 | 500 | 522 | 539 | 573 |
Top Tube MM | 522 | 532 | 546 | 556 | 568 | 583 |
Head Tube MM | 112 | 139 | 156 | 181 | 206 | 242 |
Seat Tube Angle | 74.2 | 74.2 | 74.2 | 74.2 | 74.2 | 74.2 |
Head Angle | 71.2 | 71.2 | 72.0 | 72.0 | 72.0 | 72.0 |
Rear Center MM | 410 | 410 | 410 | 410 | 410 | 410 |
Front Center MM | 583 | 599 | 597 | 609 | 621 | 635 |
Wheelbase MM | 982 | 999 | 997 | 1008 | 1020 | 1035 |
BB Drop MM | 71 | 71 | 71 | 71 | 71 | 71 |
Fork Length MM | 375 | 375 | 375 | 375 | 375 | 375 |
Fork Rake MM | 50 | 50 | 45 | 45 | 45 | 45 |
Trail MM | 63 | 63 | 63 | 63 | 63 | 63 |
Crank Length MM | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
Stem Length MM | 90 | 90 | 100 | 110 | 110 | 120 |
Stem Angle | ±8 | ±8 | ±8 | ±8 | ±8 | ±8 |
Bar Width MM | 400 | 420 | 420 | 420 | 420 | 440 |
Bar Drop MM | 125 | 125 | 125 | 125 | 125 | 125 |
Bar Reach MM | 70 | 70 | 70 | 70 | 70 | 70 |
Post Offset MM | 15 | 15 | 15 | 15 | 15 | 15 |
Standover Height MM | 719 | 750 | 782 | 805 | 825 | 859 |
Seatpost Length MM | 330 | 380 | 380 | 380 | 380 | 430 |
BMC Roadmachine Bike Sizing Chart


Intricate Swiss engineering is a given when you’re talking about BMC Switzerland. This premium approach to bikes goes back to 1994, when they began in Grenchen, Switzerland, where they are still housed today. With just 120 employees and three global offices, you could be surprised at the extent of their innovation. The in-house Impec Lab is the beating heart of BMC research and development thanks to some of the brightest minds in the industry keeping them at the cutting edge of design. After extensive development, BMC’s collection naturally becomes the choice of the world’s top athletes, who go on to win such races as the Tour de France, Team Time Trials, World Championships of various disciplines, and numerous Ironman Championships.
The sport of cycling is evolving at a breakneck speed – and BMC are at the front of the bunch, pushing the pace.
