- URS 01 Premium Carbon Frame
- MTT Micro Travel Technology
- TCC Tuned Compliance Concept Gravel
- ICS Integrated cockpit technology
- URS 01 Premium carbon fork
- Redshift suspension stem
- SRAM Rival eTap AXS / Gx Eagle 1x12 speed drivetrain
- SRAM Rival eTap AXS hydraulic disc brakes
- DT Swiss G1800 wheelset, 40mm tyres
Axles: | FRONT: 12x100mm Thru-Axle / REAR: 12x142mm Thru-Axle |
---|---|
Bottom bracket: | PF86 Bottom Bracket |
Brakes: | SRAM Rival eTap AXS HRD - Centerline Rotors (180/160) |
Chain: | SRAM Gx Eagle 12 Speed |
Chainwheel: | SRAM RIVAL 1 AXS 38T |
Derailleur rear: | SRAM Gx Eagle AXS |
Fork: | URS 01 Premium Carbon with Tuned Compliance Concept Gravel ICS Technology Integrated Brake & Hub Dynamo Routing Fender Mounts Flat Mount Disc 12x100mm Thru-Axle |
Frame: | URS 01 Premium Carbon with Micro Travel Technology Tuned Compliance Concept Gravel Gravel+ Geometry ICS Technology Stealth Cable Routing Fender and Rack Mounts PF86 Bottom Bracket Flat Mount Disc 12x142mm Thru-Axle |
Freewheel: | SRAM XG 1275 EAGLE 10-52T Cassette |
Handlebar: | Easton EA70 AX |
Handlebar stem: | ICS MTT x Redshift Suspension Stem - Integrated Cockpit Design |
Hubs: | DT Swiss 370 Spline Disc |
Rim: | DT Swiss G1800 Spline - 25mm |
Saddle: | WTB SL8 |
Season: | 2023 |
Seat post: | URS 01 Premium Carbon D-Shaped Seatpost 0mm Offset |
Tyre front: | WTB Raddler - 40mm / Clearance: 42mm (Measured Width) |
Tyre rear: | WTB Raddler - 40mm / Clearance: 42mm (Measured Width) |
Weight: | Weight Limit: 120kg |
Wheel size: | 700c |
Size | S | M | L | XL |
---|---|---|---|---|
Rider Height CM | <170 | 172-180 | 178-188 | 186-196 |
Stack MM | 538 | 569 | 603 | 641 |
Reach MM (reach) | 403 | 415 | 419 | 429 |
Seat Tube MM (st) | 431 | 459 | 492 | 527 |
Top Tube MM (tt) | 557 | 578 | 591 | 612 |
Head Tube MM (ht) | 113 | 146 | 172 | 207 |
Seat Tube Angle (sa) | 74.0 | 74.0 | 74.0 | 74.0 |
Head Angle (ha) | 70.0 | 70.0 | 70.0 | 70.0 |
Rear Center MM (rc) | 425 | 425 | 425 | 425 |
Front Center MM (fc) | 625 | 648 | 665 | 700 |
Wheelbase MM (wb) | 1041 | 1064 | 1081 | 1105 |
BB Drop MM (drop) | 69 | 69 | 69 | 69 |
Fork Length MM (fl) | 407 | 407 | 407 | 407 |
Fork Rake MM (fr) | 45 | 45 | 45 | 45 |
Trail MM (trail) | 77 | 77 | 77 | 77 |
Crank Length MM | 170 | 172.5 | 172.5 | 175 |
Stem Length MM | 70 | 70 | 80 | 90 |
Bar Width MM | 420 | 420 | 440 | 440 |
Bar Drop MM | 120 | 120 | 120 | 120 |
Bar Reach MM | 80 | 80 | 80 | 80 |
Standover Height mm | 748 | 778 | 810 | 846 |
Seatpost Length MM | 330 | 380 | 430 | 430 |
BMC Road Bike Sizing Chart


Intricate Swiss engineering is a given when you’re talking about BMC Switzerland. This premium approach to bikes goes back to 1994, when they began in Grenchen, Switzerland, where they are still housed today. With just 120 employees and three global offices, you could be surprised at the extent of their innovation. The in-house Impec Lab is the beating heart of BMC research and development thanks to some of the brightest minds in the industry keeping them at the cutting edge of design. After extensive development, BMC’s collection naturally becomes the choice of the world’s top athletes, who go on to win such races as the Tour de France, Team Time Trials, World Championships of various disciplines, and numerous Ironman Championships.
The sport of cycling is evolving at a breakneck speed – and BMC are at the front of the bunch, pushing the pace.
