Marin Alcatraz 1 Dirt Jump Bike Blue Fade
5% Best Price Guarantee
If you find a cheaper price, we will beat it by 5%*
- Applies to any cheaper price found in New Zealand.
- When the competitor's final price inclusive of any taxes and delivery fees.
- Excludes Garmin products, other exclusions apply.
Perfect Ride Guarantee
If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »
Free Bike Build
We'll build your bike for free when you click and collect at any 99 Bikes store.
First Free Tune-up
Every bike come with a complimentary free tune-up and safety check. Learn more »
- Series 3 aluminum frame built for the hard knocks
- Marin Series 2 CroMo Suspension Corrected Fork
- Single speed drivetrain packed with quality Marin components
- Tektro mechanical disc brakes
- Ambidextrous cable routing for easy brake swapping
- Marin Custom Extrusion Rims
- Vee Tire Co. XCV 26 x 2.25” tyres
- Available in two sizes, Short (155-175cm) & Long (168-191cm)
The Alcatraz was designed from the ground up to be the best dirt jump and slopestyle bike you have ever ridden. Marin worked hand-in-hand with Matt Jones to define the exact needs of a modern dirt jump frame and are proud to release the complete Alcatraz into the world. At home boosting your local 6-pack, ripping up the pump track, or hitting the local skate park the Alcatraz has what you need to take care of business.
The Alcatraz 1 offers up a Series 3 aluminum frame built for the hard knocks, it’s stiff enough for lightning-fast acceleration and tough enough for the heavy hits. Short stays keep manuals easy and ambidextrous cable routing means you can run your brake on the left or right of the bars. There’s a suspension-corrected CrMo fork, front and rear Tektro mechanical disc brakes, Marin Custom Extrusion 26” Rims rolling on Vee Tire 2.25” rubber and plenty of bombproof Marin components. Best of all, it’s available in two frame sizes, regular and long to suit all rider heights.
| Accessories: | Marin Chain Tension Device |
|---|---|
| Bottom bracket: | External Sealed Cartridge Bearings |
| Brakes: | Tektro MD-M280 Mechanical Disc |
| Cassette: | 14T Single Speed Cog |
| Chain: | KMC HL-1 |
| Crankset: | Marin Forged Alloy, Alloy 32T Chainring, 104mm BCD |
| Fork: | Marin Series 2 CroMo 26", Suspension Corrected, 100x9mm Dropouts |
| Frame: | Series 3 6061 Aluminum, 26” Wheels, 135x10mm Horizontal Single Speed Dropouts, 73mm Threaded BB, ISCG 05 Tabs |
| Grip: | Marin MTN, Closed End |
| Handlebar: | Marin Riser, 6061 Double Butted Aluminum, 31.8mm at center bulge, 38mm Rise, 750mm Width, 4º Up, 9º Back |
| Handlebar stem: | Marin 3D Forged Alloy, 31.8mm clamp, 40mm extension |
| Headset: | FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2” |
| Hubs: | FRONT: Forged Alloy, Bolt On 3/8" Axle, 100mm Spacing / REAR: Forged Alloy, 135x10mm, Bolt-On, Quad Sealed Bearings, Disc, 32H |
| Pedals: | Alloy Platform |
| Rim: | Marin Custom Extrusion, 27mm Inner, Pinned Joint |
| Rotor front: | 160mm Rotor |
| Rotor rear: | 160mm Rotor |
| Saddle: | Marin DJ Saddle |
| Season: | 2024 |
| Seat post: | Marin Alloy, 30.9mm |
| Spokes: | 14g Black Stainless Steel |
| Tyres: | Vee Tire Co. XCV 26x2.25”, LSG Compound, Wire Bead |
| Wheel size: | 26" |
| Short | Long | |
|---|---|---|
| Stack | 575 | 580 |
| Reach | 385 | 430 |
| Headtube Angle | 69° | 69° |
| Headtube Length | 115 | 120 |
| Seattube Angle | 69° | 69° |
| Seattube Length | 320 | 320 |
| Toptube Effective | 600 | 646 |
| BB Height | 317 | 317 |
| BB Drop | 22 | 22 |
| Chainstay | 395 | 395 |
| Wheelbase | 1037 | 1083 |
| Standover Height | 370 | 400 |
| Fork Offset | 42 | 42 |
| Seatpost Diameter | 30.9 | 30.9 |
| Handlebar Width | 750 | 750 |
| Stem Length | 40 | 40 |
| Crank Length | 170 | 170 |
All lengths in millimeters
