The San Quentin 2 features a series 3 aluminium frame, with more advanced tube forming, more complex dropouts, post mount disc tabs, full internal cable routing, and a boost 148mm thru-axle. ISCG 05 tabs are included for easy chain retention device installation for rowdier riders. Taking cues from the Alcatraz, the San Quentin provides all the benefits of the DJ style with massive stand over, slick frame tubes, and a sexy paint job. The slack head tube angle paired with a steep seat tube angle create a ride that will fly uphill with perfect front wheel precision but then descend like it’s on rails. The balanced rider position thanks to the steep seat tube puts your weight between the wheels for impressive climbing and handling on flats, while the slack front end and short rear center help to pull you through the rough descents and corners with an intuitive feel.
Bottom bracket: | External Sealed Cartridge Bearing |
---|---|
Brakes: | Tektro M535 4-Piston Hydraulic |
Cassette: | Shimano CS-5100-11, 11-51T |
Chain: | Shimano CN-LG500 |
Crankset: | Marin Forged Alloy w/ Hollow Spindle and Integrated Steel 32t Narrow Wide Chanring, Boost Spacing |
Derailleur rear: | Shimano Deore, 11-Speed, SGS |
Fork: | X-Fusion Slide Boost RC, 29", 140mm Travel, Compression and Rebound Adjustment, 110x15mm Thru Axle, 44mm Offset |
Frame: | All New Series 3 6061 Aluminum, Double Butted, Internal Cable Routing, 12x148mm Thru-Axle, 73mm Threaded BB |
Grip: | Marin Grizzly Lock On |
Handlebar: | Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back |
Handlebar stem: | Marin 3D Forged Alloy, 35mm |
Headset: | FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2” |
Hubs: | FRONT: Shimano HB-TC500, 110x15mm / REAR: Shimano FH-TC500, 148x12, MicroSpline Freehub Body, Centerlock Disc, 32H |
Pedals: | Marin Oso OE Flat |
Rim: | Marin Aluminum Double Wall, Disc Specific, 29mm Inner, Pinned Joint, 32H, Tubeless Compatible |
Rotor front: | 180mm Rotor |
Rotor rear: | 180mm Rotor |
Saddle: | Marin Speed Concept |
Season: | 2024 |
Seat post: | TranzX, YSP18, 1x Remote, All Sizes 170mm Travel, 30.9mm |
Spokes: | 14g Black Stainless Steel |
Tyres: | Vee Tire Co, Flow Snap, 29x2.6", MPC Compound, Wire Bead |
Wheel size: | 29" |
S | M | L | XL | |
---|---|---|---|---|
Stack | 632 | 636 | 645 | 650 |
Reach | 422 | 450 | 470 | 500 |
Headtube Angle | 64° | 64° | 64° | 64° |
Headtube Length | 115 | 120 | 125 | 130 |
Seattube Angle | 77° | 77° | 77° | 77° |
Seattube Length | 330 | 380 | 410 | 420 |
Toptube Effective | 568 | 596 | 619 | 650 |
BB Height | 316 | 316 | 316 | 316 |
BB Drop | 50 | 50 | 50 | 50 |
Chainstay | 430 | 430 | 430 | 430 |
Wheelbase | 1182 | 1212 | 1236 | 1268 |
Standover Height | 650 | 683 | 688 | 695 |
Fork Offset | 44 | 44 | 44 | 44 |
SeatPost Diameter | 30.9 | 30.9 | 30.9 | 30.9 |
Handlebar Width | 780 | 780 | 780 | 780 |
Stem Length | 35 | 35 | 35 | 35 |
Crank Length | 170 | 170 | 170 | 170 |
All lengths in millimeters
Marin San Quentin Bike Sizing Chart
