- Tough all-aluminium chassis with integrated 750 Wh battery
- Powerful Shimano EP8 drive unit
- Assist speeds up to 32 km/h
- Approx range 30 - 80km on singletrack, 100 - 270km on flat
- Mixed wheel size setup with 140/130 mm travel split
- Quality SR Suntour suspension
- Smooth Shimano drivetrain and powerful four-piston brakes
- Fully equipped with mudguards, rack, lights and kickstand
The eONE-FORTY might be the little sibling to Merida’s multiple award and test winning eONE-SIXTY, but when it comes to providing agile trail handling with superb flow and fun, it plays second fiddle to no-one, it’s the perfect partner for all kinds of adventures. The trail-specific, balanced geometry is paired to a mixed 29er/27.5” wheel size setup that delivers flow and fun for riders of all abilities, while a steeper seat angle boosts climbing capability, something ideal for an all-day e-bike mission. The low bottom bracket and lower standover height mean extra confidence while the 140 mm of front wheel and 133 mm of rear wheel travel offer up control, comfort and real rough terrain capability.
Accessories: | REAR CARRIER: MERIDA MIK HD Carrier with Spring clip & Spanninga rear light / KICKSTAND: Atranvelo ED-100-PC |
---|---|
Battery: | Trendpower Internal Battery 750Wh |
Chain: | Shimano LG500 |
Chainwheel: | FSA 1x Steel Megatooth Chainring |
Display: | Shimano SC-EN600 |
Fender: | Winning EOF-204 |
Fork: | SR Suntour Zeron 36 X |
Frame: | eONE-FORTY LITE IV |
Freewheel: | Shimano LG400 |
Grip: | MERIDA EXPERT EC |
Handlebar: | MERIDA EXPERT eTR |
Handlebar stem: | MERIDA EXPERT eTR II |
Headset: | Acros ICR MERIDA EXTERNAL neck w/ Blocklock |
Motor drive unit: | Shimano EP801 |
Pedals: | VP VPE-527 |
Rim: | MERIDA COMP TR II |
Saddle: | MERIDA EXPERT SL |
Seat clamp: | MERIDA EXPERT |
Seat post: | MERIDA EXPERT TR II |
Shock: | SR Suntour Edge Plus |
Spokes: | Black stainless |
Wheel size: | 29" / 27.5" (Mullet Bike) |
Frame Size | M | L | XL | XXL |
Tire Sizes | 29/27.5" | 29/27.5" | 29/27.5" | 29/27.5" |
Seat Tubes Mm | 415 | 430 | 450 | 470 |
Top Tubes Mm | 581 | 603 | 624 | 645 |
Chain Stays Mm | 439.5 | 439.5 | 439.5 | 439.5 |
Head Tube Angles Deg | 66.5 | 66.5 | 66.5 | 66.5 |
Seat Tube Angle Deg | 76.5 | 76.5 | 76.5 | 76.5 |
Bottom Bracket Drops Mm | 25 | 25 | 25 | 25 |
Head Tube Lengths Mm | 115 | 120 | 125 | 130 |
Fork Lengths Mm | 551 | 551 | 551 | 551 |
Reachs Mm | 430 | 450 | 469 | 489 |
Stacks Mm | 627 | 631 | 635 | 640 |
Wheel Base Mm | 1182 | 1204 | 1226 | 1248 |
Stand Over Height Mm | 730 | 727 | 733 | 747 |
Merida Electric Mountain Bike Sizing Chart
Merida is an international bike brand with its headquarters in Taiwan, the R&D department is based near Stuttgart in Germany. To be based in Germany has historical reasons for MERIDA but the precise location was chosen specifically because the region around Stuttgart is one of the hot spots of the automotive and machine building industry which Germany is famous for and attracts a hugely skilled design and engineer labor force.
The Merida team are more than just highly trained and experienced bicycle creators – they simply love everything ‘bike’. Most of their R&D staff are daily bike commuters while others are serious mountain bikers, who regularly compete in Marathon, Enduro and Downhill competitions, or licensed road racers and even ambitious Ironman triathletes. Get the behind the scenes view of the Merida R&D centre and meet some of their key members of staff in the below video.
